Product details

About This

  • FULL PORT BRASS BODY: 1/2 in full-port bore delivers full, unrestricted flow with minimal pressure drop; brass body with PTFE ball seat handles water, oil, gas, and air lines up to 90 °C media temperature
  • THREE-LIGHT STATUS INDICATOR: Built-in open, closed, and stuck lights on the unit show valve position at a glance; they confirm position only and do not monitor or regulate flow, and a motorized actuator drives on/off shutoff in 6-8 seconds
  • 2-WIRE AUTO RETURN: A basic 2-wire hookup carries power only and lets the valve de-energize after moving to reduce heat buildup; the ball returns to fully open when power is removed, a reliable alternative to solenoid valves
  • NORMALLY OPEN 9-36 V AC/DC: Wide 9-36 V AC/DC input keeps the passage open until the valve is powered; a normally open design suits lines that stay open for long runs, drawing 5 W with 2 Nm torque
  • BUILT FOR AUTOMATION: 1/2 in NPT connection and an 80000 to 100000 cycle service life suit home water systems, water treatment, irrigation, and water filters; PTFE ball seat and EPDM seal give steady shut-off

Overview

  • Material : Brass
  • Brand : U.S. Solid
  • Item dimensions L x W x H : 4.33 x 3.55 x 3.55 inches
  • Exterior Finish : Brass
  • Inlet Connection Size : 0.5 inches
  • Inlet Connection Type : National Pipe Tapered
  • Outlet Connection Type : FNPT
  • Number of Ports : 2
  • Outlet Connection Size : 0.5 inches
  • Unit Count : 1 Count
