U.S. Solid 1 in Brass Motorized Ball Valve, Manual Override, Normally Open, Standard Port, 9-24V AC/DC, 2-Wire Auto Return, NPT
U.S. Solid 1 in Brass Motorized Ball Valve, Manual Override, Normally Open, Standard Port, 9-24V AC/DC, 2-Wire Auto Return, NPT
Ball Valves
Product details
About This
- Normally Open Auto Return: With a 2-wire connection, this valve closes when powered and automatically returns to the fully open position when power is removed — ideal for fail-safe water, air, or gas shutoff systems.
- Wide Voltage Compatibility: Operates on any AC or DC supply from 9V to 24V, opening or closing in 6 to 8 seconds, with a maximum power draw of 5W and maximum torque of 2.5 N·m for reliable actuation.
- Brass Body with PTFE Seal: The valve body is machined brass with a PTFE seal and IP65-rated enclosure, rated for media temperatures from 32 degrees F to 194 degrees F and working pressure up to 145 psi.
- 1 in NPT Standard Port Sizing: Features a 1-inch National Pipe Thread connection with a 20mm orifice — fits standard 1 in NPT pipe systems used in irrigation, HVAC, plumbing, and industrial flow control applications.
- Long Service Life with Manual Override: Rated for 80,000 to 100,000 actuation cycles and includes a manual override function, allowing hand operation during power outages or commissioning without external tools.
Overview
- Material : Brass
- Brand : U.S. Solid
- Item dimensions L x W x H : 4.02 x 3.23 x 3.23 inches
- Exterior Finish : Brass
- Inlet Connection Size : 1 inches
- Maximum Operating Pressure : 10 bar
- Number of Ports : 2
- Unit Count : 1 Count
- Manufacturer : U.S. Solid
- Number of Items : 1
